Only using one probe reached super frequency responsibility, high reliable tip-touch range keys with convex. No any concerns about slip or being misplaced. Replaceable probe of quality eliminating detection non-linearity, having uniform scales; easy to read.

1.Specifications

1.1 Measuring Rage:

0.8mV～10V,-47dBm～＋33dBm

Extended to 300V using the 40dB divider (optional)

1.2 Operating Frequency Range:

100Hz～1.5GHz

1.3 Basic Error:

±2.5％

1.4 Input Impedance

15KΩ/2PF

1.5 Size:

210×140×245（mm）

(Specifications which should be referred to instruction manual are subject to change without notice.)
